Insulin Syringe Sizes Chart

Insulin syringe with needle comes in various sizes.

Select the smallest syringe size suitable for your insulin dose. Smaller syringes have more spaced-out and visible measuring lines on their barrels. When picking a syringe size, consider both the required insulin units and your ability to read the markings on the barrel.

For children, especially those needing tiny insulin doses, or individuals with vision difficulties, a 0.3ml or 0.5ml syringe is usually the most appropriate choice.

An adult requiring a larger insulin amount might find a 1ml syringe more suitable.

U-40 Insulin Syringe Red Cap

U-100 Insulin Syringe Orange Cap

Insulin Syringe Size & Dosage Information

Horizon offers insulin syringes in different sizes to suit various diabetic needs and doses. The insulin syringe sizes relate to its capacity, while the insulin syringe needle sizes correspond to the needle's gauge and length. Horizon insulin syringes come in three body sizes: 1cc, 5/10cc, and 3/10cc, indicating the syringe's capacity. The markings for U-100 insulin on each size are as follows: Size / Max Dosage / Increments 1cc / 100 units / 2 units 5cc / 50 units / 1 unit 3cc / 30 units / 1 unit. Choose the insulin syringe size based on your highest injection dose. For instance, if you take 20 units, you can use a 0.5cc/50 unit or a 0.3cc/30 unit syringe insulin. For 60 units, go for a 1cc/100 unit insulin syringe. Generally, smaller syringe sizes have clearer markings. For example, it's easier to read 35 units on a 5/10cc /50 unit syringe than on a 1cc/100 unit one. Similarly, a 15 unit dosage is clearer on a 3/10cc /30 unit syringe than on a 5/10cc /50 unit syringe.

Insulin Syringe Description

An insulin syringe disposal is a specialized medical tool designed for the precise administration of insulin, a hormone crucial for regulating blood sugar levels in individuals with diabetes.

An insulin syringe consists of six parts: a needle, a barrel, a plunger, a piston, a protective cap and an end cap.

The needle is small and covered with a thin layer of silicone to make it gentle on the skin and reduce discomfort. Before use, the needle is protected by a cap.

The barrel is a slim, long chamber that holds the insulin. It has marked lines to measure the insulin units.

The plunger, a long and slender rod, fits snugly inside the barrel. It can easily move up and down to draw insulin into the barrel or push it out through the needle. The plunger's lower end has a rubber seal to prevent leaks. This rubber seal lines up with the marked lines on the barrel to measure the right insulin amount.

The  finger flange & thumb rest,  well-designed for a comfortable and secure grip, ensuring easy control.

The  protective cap,  keeps the needle clean and safe from damage.

The  end cap,  preserves syringe sterility during shipping.

● The orange needle cap (sheath) helps you recognize the U-100 insulin syringe easily.

● The red needle cap (sheath) is designed for simple identification of the U-40 insulin syringe.

● The cannula is made from stainless steel.

● The hub is crafted from polypropylene.

● It follows ISO color coding.

● It has graduations marked for single units.

● You can get it in either PE or Blister pack packaging.

● It is free from DEHP and natural rubber latex materials during manufacturing.

● Each unit is sterile, meant for one-time use, and individually sealed.

● It contributes to diabetes care by supporting its management.

The Horizon Standard Insulin Syringe offers a combination of affordability and comfort tailored to meet patients' daily insulin administration requirements. This syringe is designed to cater to various insulin needs in a convenient manner. Each box of this insulin syringe contains 100 pieces, ensuring cost-effectiveness. Our manufacturing process adheres to ISO8537 standards, with plastic components crafted using advanced hot runner molds. The syringe features ultra-thin needles that are securely affixed, and its design prioritizes patient comfort with a sharp, minimally painful puncture tip. I.U and CC calibration, graduation lines are printed in bold for easy reading.

The Horizon Standard Insulin Injection Syringe is meticulously crafted to reduce errors through their premium construction and user-friendly functionality. This syringe for insulin injection is designed without dead space, guaranteeing precision in dosages. Their secure fit ensures leak-proof operation, minimizing wastage. Additionally, this syringe for insulin, coated with a protective film, are completely latex-free. Enhanced sterility is achieved through individual protective needle caps and plunger caps, contributing to the utmost cleanliness of Horizon Standard Insulin Syringes.

The Horizon Standard Insulin Syringe is crafted and produced with a primary focus on providing consumers with unparalleled comfort. The syringe insulin features uniquely designed needles that undergo a triple-bevel cutting process, resulting in an exceptionally sharp tip. These insulin injection syringe needle is further enhanced through electro-polishing to eliminate even microscopic imperfections, and they are film-coated for seamless injections. Should you be in search of an OEM or ODM insulin syringe supplier in China, we are dedicated to offering both competitive prices and exceptional customer service.

Standard Insulin Syringe Features

Standard Insulin Syringe Benefits

Insulin syringes are medical devices specifically designed for administering insulin to individuals with diabetes. This syringe for insulin offers several benefits that make them a crucial tool for managing diabetes and maintaining optimal health. Here are some of the key benefits of using syringe insulin injection:

Standard Insulin Syringe Specifications

Insulin Syringe Ordering information

Insulin Syringe PE Packing

Insulin Syringe Blister Packing

PE Packing Insulin Injection Syringe

Blister Packing Insulin Injection Syringe

Insulin Syringe Pictures

As a single use insulin syringe manufacturer in China, our insulin syringe for sale is of excellent quality, good price and supreme service. Please find below some picture of insulin syringe.

0.5cc Insulin Syringe

1ml insulin syringe u-100

u-40 insulin syringe 1 ml

Insulin Syringe Uses

The insulin syringe serves a critical purpose in the management of diabetes, enabling individuals to administer insulin accurately and effectively. This syringe is specifically designed to accommodate insulin dosages and ensure precise delivery, playing a pivotal role in maintaining stable blood sugar levels.

Insulin Syringe Use

Insulin Syringe Uses

Insulin Syringe Drawing

Main Components of an Insulin Syringe:

Barrel: The cylindrical body of the syringe that holds the insulin.

Plunger: The movable component inside the barrel used to draw and push insulin.

Needle: The thin, pointed metal tube for injecting insulin into the body.

Needle Cap: A protective cover for the needle to prevent contamination.

Graduation Marks: Measurement indicators on the barrel to show the insulin dosage.

Finger Flange & Thumb Rest: Ergonomic features for comfortable grip and control.

Protective Caps (Needle & Plunger): Covers to maintain sterility during storage and transport.

Insulin Syringe Types

There are many different insulin syringe types. Please find the following type of insulin syringe. Different types of insulin syringes cater to various needs and preferences, ensuring effective and comfortable insulin administration for individuals managing diabetes.

R1) U-100 Insulin Syringes: Designed for insulin with a concentration of 100 units per milliliter (U-100). These syringes are the most common and widely used.

R2) U-40 Insulin Syringes: Intended for insulin with a concentration of 40 units per milliliter (U-40). These are less common and used in some regions.

R3) Fixed Needle Insulin Syringes: Syringes with a pre-attached needle for convenience and ease of use.

R4) Detachable Needle Insulin Syringes: Syringes where needles can be attached or detached, allowing for needle customization.

R5) Safety Insulin Syringes: Equipped with safety features like retractable needles to reduce the risk of accidental needle sticks.

R6) Low Dead Space Insulin Syringes: Designed to minimize the amount of insulin left in the syringe after injection, reducing wastage.

R7) Insulin Pen Needles: Not traditional syringes, but needle attachments for insulin pens, offering discreet and convenient dosing.

R8) Micro-Dose Insulin Syringes: For highly precise dosing in small increments, suitable for people with specific insulin needs.

R9) Volume-specific Insulin Syringes: Syringes with varying capacities (e.g., 1cc, 0.5cc) to match specific dosage requirements.

R10) Short and Long Needle Insulin Syringes: Varied needle lengths to accommodate different injection sites and preferences.

If you are in the insulin syringe market, want to buy insulin syringe, buy 1 ml insulin syringe, buy 0.5 ml insulin syringe, buy 0.3 ml insulin syringe,  looking for china insulin syringe supplier, please feel free to ask the insulin syringe factory price from us. We can provide you most common insulin syringe, standard insulin syringe, short tip insulin syringe, smallest insulin syringe, ultra comfort insulin syringe, best insulin syringe, china insulin syringe, with best price, we can also provide free insulin syringe samples for you to test the quality. Equipped with the advanced automatic production lines, we can also support you with fast insulin syringe delivery.

Resources

Standard Insulin Syringe - Horizon.pdf

Insulin Syringe Manufacturing Process

FAQ

❓ 1. How to inject insulin with a syringe ? How to use an insulin syringe ?

Keep in mind that we are just providing general information, and it's important to follow your doctor's instructions or the guidelines provided with your specific insulin and syringe. If you're unsure or uncomfortable with the process, always consult a medical professional.

Here's a step-by-step guide on how to inject insulin using a syringe:

Materials you'll need:

Insulin vial or pen

Insulin syringe (U-100 syringe for U-100 insulin)

Alcohol swab

Cotton ball or gauze

Sharps disposal container

Steps:

Wash Your Hands: Start by washing your hands thoroughly with soap and water. This helps prevent infection.

Prepare Your Supplies: Gather all the necessary supplies on a clean, flat surface. Make sure the insulin vial is at room temperature, as cold insulin can be uncomfortable to inject.

Check the Insulin: Examine the insulin in the vial. If it looks cloudy or has particles, gently roll the vial between your palms to mix it. Do not shake the vial vigorously, as this can cause bubbles.

Clean the Injection Site: Choose an injection site (common areas include the abdomen, thighs, and upper arms). Clean the chosen area with an alcohol swab and let it dry. This helps prevent infections.

Draw Up the Insulin:

Remove the cap from the insulin vial and wipe the rubber stopper with an alcohol swab.

Remove the cap from the syringe needle and draw air into the syringe equal to your insulin dose.

Insert the needle into the rubber stopper of the insulin vial.

Inject the air into the vial and then turn it upside down.

Slowly draw up the correct dose of insulin into the syringe, making sure the tip of the needle is submerged in the insulin.

Remove Air Bubbles: Gently tap the syringe to bring any air bubbles to the top. Slowly push the plunger to expel the air bubbles back into the vial. Then, draw up a little extra insulin to ensure you have the correct dose.

How to get air bubbles out of insulin syringe ?

It's important to get rid of air bubble in insulin syringe because injecting air instead of insulin can affect the accuracy of your dose. If you're ever unsure, ask your healthcare provider or a nurse to show you how to do this correctly.

Inject the Insulin:

Pinch a fold of skin at the cleaned injection site.

Hold the syringe like a pencil or a dart, and insert the needle into the pinched skin at a 90-degree angle (or the angle recommended by your healthcare provider).

Inject the insulin slowly and steadily by pushing the plunger all the way down.

Remove the Needle: After the insulin is injected, count to 5 or 10 before pulling out the needle to ensure the insulin is properly absorbed.

Apply Pressure and Dispose:

Use a cotton ball or gauze to apply gentle pressure to the injection site.

Carefully dispose of the used syringe in a sharps container. Do not recap the needle.

Record the Injection: Keep a record of the injection, including the date, time, dose, and injection site. This helps you track your insulin regimen.

Remember, if you're new to injecting insulin or have any concerns, it's best to consult with your healthcare provider or a diabetes educator for personalized guidance and support.

❓ 2. How many times we can use insulin syringe ?

Insulin syringes are generally designed for single-use only. This means you should use a new, sterile syringe for each insulin injection. Reusing syringes can increase the risk of contamination, infection, and inaccurate dosing. After using a syringe, it should be safely disposed of in a designated sharps container to prevent accidental needle sticks and protect others.

❓ 3. u 40 insulin syringe vs u 100

U-40 Insulin Syringe:

A U-40 insulin syringe is designed to measure and deliver insulin that has a concentration of 40 units of insulin per 1 milliliter (ml) of liquid.

This syringe is used for insulin preparations that are less concentrated.

The insulin syringe markings on the syringe barrel are adjusted to accurately measure doses of U-40 insulin.

U-100 Insulin Syringe:

A U-100 insulin syringe is used for insulin that has a concentration of 100 units of insulin per 1 milliliter (ml) of liquid.

U-100 insulin is more concentrated than U-40 insulin.

The insulin syringe markings on the syringe barrel are designed to measure doses of U-100 insulin.

Key Difference:

The main difference between U-40 and U-100 insulin syringes is the concentration of insulin they are designed for. U-40 syringes are for less concentrated insulin, while U-100 syringes are for more concentrated insulin.

It's very important to use the correct syringe for the type of insulin you are prescribed. Using the wrong syringe can lead to incorrect dosing, which can affect your blood sugar control. Always follow your healthcare provider's instructions and the labeling on your insulin and syringes to ensure you're using the right ones. If you're unsure, consult your doctor or pharmacist for guidance.
